Don’t be mean

[Some on Twitter noted that I should be using milliseconds instead of FPS. This kind of misses the point, but let’s avoid distractions, here’s the article with that change. The sad part is that you then miss my hilarious joke about how I use FPS in the article, because if I used SPF you’d think I was talking about tanning. Which makes me think of another joke about rendering cows and the time it then takes to tan their hides. I’m full of great dad jokes.]

I think I’m reading “The Economist” too much, as I keep trying to come up with punny article titles. Sorry.

So, how do you measure a representative value for milliseconds per frame?

I don’t care about the mechanics, which timer call you use, etc. Just assume you successfully start timer/end timer and get some length of time in milliseconds for the frame. What do you do with these timings?

I usually see things such as an average, or a running average (average of last 20 or 50 or 100 or whatever frame times). I think this is mostly bad. As someone pointed out, almost everyone has more than the average number of legs. I find the same: in a given run there can sometimes be some frames where things noticeably slow down for whatever reason, some load on the computer. What you’re often trying to measure (as a graphics developer) is the performance of the rendering system itself, not the computer’s overall performance.

So, I currently use one of these two, or both: shortest time, or median time, over whatever set of frame times I have. Both have their uses. Shortest time is justifiable (to me, at least) because, assuming you have a very fine-grained timer, your best time is in some sense the “purest” measurement of the time a frame takes. Whatever other processes in your system are slowing down the other frames isn’t your concern. The timer doesn’t lie, you really did go that fast for one frame.

The other measure I’m OK with is the median. If your benchmarking system is going through a series of different frames (an animation or simulation is running, or the camera is orbiting, etc.), then grabbing the median frame is good. Choosing it instead of the average then doesn’t give so much weight to outliers. Better yet, graph the results and see whether the outliers are consistent.

Update: A number of game and VR developers pointed out that their major interest is maximum frame time. Makes sense: for a good experience (especially with VR) you don’t want to drop below your target of 30 FPS, 60 FPS, or 90 FPS.

My point is that the average, the mean, is not so good: often external slowdowns throw off the average enough and at random enough intervals that the average is very noisy and so, pretty useless. Taking the median, the central time of the sorted set, cuts out much of this variance, making each sample have an equal effect on the result.

Anyway, that’s where I’m at with benchmarking. What do you do? Comment here, tweet-reply, or email me at erich@acm.org and I’ll summarize.

p.s. pro tip: walk through your rendering pipeline every once in awhile, watching each step. It’s hard to really know where the time goes without doing so. I did this last week while looking at another bug and found a little logic error was causing a certain path to always do an additional post-process when it usually wasn’t needed. Free performance boost with a two-line fix! But, not something discoverable by benchmarking, because the variance is too much to notice “just” a few frames of difference.

This happens every few years. My favorite lucky find was around 15 years ago, walking through code in an established project and seeing that it was rendering twice for each time it displayed. A one-line change gave us 2x performance.

Three.js example thumbnails page

I made a page of thumbnail images of the 297 three.js examples. Here it is:

http://www.realtimerendering.com/threejs/

The three.js site used to have a page like this. I’m not sure why it disappeared, but now I don’t care, as I can more easily find demos I’ve looked at before but then forgot the names.

Bonus links: Stemkoski and Yomotsu also have useful demo pages, which used to be prominently linked from the three.js site but now are not.

Two ways to think about transforms

I was just answering a question for the Udacity Interactive Graphics MOOC. I had made a rather confusing lecture, much more involved and less informative that I would have liked, so today I wrote a re-do (sadly, it’s not easy to make a new video, since step 1 is “fly from Boston to San Francisco”). I’m still not thrilled with my description – what do you think? Is there a better way to talk about this subject? Anything I could improve? Surprisingly, this course still gets about 35 sign-ups a day (though I’m guessing maybe one of those actually finishes), so it’d be nice to make this lesson better.

Background: up to this point in the course I’d been showing how you typically write down transforms from right to left (OpenGL-style column-major matrices), e.g. “TR” means “rotate the object, then translate it (in world space) to some location.” In this lesson I wanted to point out that you can also read the transform order from left to right.

=================

You’re at 41 Avenue George V in Paris. Someone comes up and asks “How can I see the Arc de Triomphe?” You tell them, “Go up two blocks and then turn to the left – you can’t miss it.” Indeed, at 101 Avenue des Champs-Élysées he can see L’Arc de Triomphe.

So if you wanted to take this person and apply these two transforms, translation T (walk two blocks) and rotation R (turn about 60 degrees to the left), how would you write that out? Think about it for a minute, then scroll down for the answer. (And I like the disembodied arm to the right from Google’s street view).

2016-04-09_153558

The order is (right-to-left “application order”): TR. That is, you want to apply the rotation first, so that it doesn’t affect the translation. So you rotate the person 60 degrees to the left, then you translate him north two blocks north, which is then not affected by the rotation.

If you incorrectly used order RT, you would first translate him north two blocks, so far so good. But, as you saw in the snowman lesson, rotating after translation means the object is rotated around the origin from his present location; in this case, the person’s starting location is the origin. So performing a translation, then a rotation, would move him up two blocks north, then rotate him in a circle with a 2 block radius by 60 degrees, putting him somewhere else in the city (Rue Euler, I guess, which is a great coincidence that it’s named for a famous mathematician).

I hope you accept TR is the right order, then. But, to describe directions we definitely first said “perform T” – walk two blocks north – “then perform R” – rotate to the left 60 degrees. So we talk about directions in a left-to-right fashion. This may seem odd, as we are then describing the last transform that we apply, T, if we actually want to position the man in his environment.

The key thing here, and the point of the lesson, is that by specifying T first, we’re saying to the man, change your frame of reference to be 2 blocks north. From this new frame of reference, then rotate 60 degrees around where you’re standing, your new origin. It’s how we talk about directions. We don’t say “when you get to your final position, rotate 60 degrees left. Then, to get to your final position, walk two blocks north.”

The person walking has his own frame of reference, where he’s always the origin, and rotations are done relative to whichever way he’s facing at the time. To specify transforms when talking in these terms, an object-centric way of describing things, we describe “from left to right.” When we’re looking at the world and want to think how to make some other object take on a particular orientation and position, we tend to work from right to left, getting it oriented and them moving it into position.

However, it all depends. Moving a couch up a flight of stairs, down a hall, and next to a wall in room is a series of transforms, and again we specify them from left to right. We could also shortcut the process if we don’t care about the intermediate steps along the way. Say the couch is facing north, and we know it’ll end up facing east. We could specify the one 90 degree rotation to get it to face east, then the one XYZ translation to move it directly to its desired location – right to left order, so that the rotation doesn’t interfere with the translation.

The final effect of the transforms – a series of moves or the direct rotation and translation – have the same final effect. The point is, each way of thinking has its uses.

Seven Things for April 6, 2016

Let’s get visual. Last in the series, for now.

Seven Things for April 5, 2016

All linked out yet? Here’s more worthwhile stuff I’ve run across since last SIGGRAPH.

Seven Things for April 4, 2016

Next in the continuing series. In this episode Jaimie finds that the world is an illusion and she’s a butterfly’s dream, while Wilson works out his plumbing problems.

Seven Things for April 3, 2016

The things:

Reuse of photos of public domain paintings, and of wire-frame models

It’s rainy out, and I’m trying to avoid coding for Mineways and collecting code for JGT, so time to blog a little.

Some years ago I read the book The Public Domain about copyright and learned an interesting tidbit: photos of public domain paintings or photos are not covered by copyright in the U.S., they’re free to reuse.

Here’s the relevant bit from Wikipedia:

Reproductions of public domain works

The requirement of originality was also invoked in the 1999 United States District Court case Bridgeman Art Library v. Corel Corp. In the case, Bridgeman Art Library questioned the Corel Corporation‘s rights to redistribute their high quality reproductions of old paintings that had already fallen into the public domain due to age, claiming that it infringed on their copyrights. The court ruled that exact or “slavish” reproductions of two-dimensional works such as paintings and photographs that were already in the public domain could not be considered original enough for protection under U.S. law, “a photograph which is no more than a copy of a work of another as exact as science and technology permits lacks originality. That is not to say that such a feat is trivial, simply not original”.[30]

Another court case related to threshold of originality was the 2008 case Meshwerks v. Toyota Motor Sales U.S.A. In this case, the court ruled that wire-frame computer models of Toyota vehicles were not entitled to additional copyright protection since the purpose of the models was to faithfully represent the original objects without any creative additions.[31]

The wire-frame case is obviously relevant to computer graphics. There’s a rundown of other countries’ laws on Wikimedia Commons’ site.

Private collections are within their rights to limit access as they wish, as misguided as I think it is to sell public domain works to the public. I have a problem with any public institution invoking protection of photos of works, since there’s no legal basis for this.

The Public Domain is free to download and worth a read. To be honest, after a bit I skimmed chapter 2, but I particularly enjoyed chapter 7, a case study in which the U.S.’s more permissive rules on what is in the public domain (“sweat of the brow” works are not copyright in the U.S.) are contrasted with Europe’s more restrictive laws.

Oh, and if you like to read about copyright (you weirdo), you might enjoy The Idealist: Aaron Swartz and the Rise of Free Culture on the Internet. The second half is worthwhile, though quite sad, and a story I suspect many of us know to some extent. The first half is about the evolution of copyright laws in the United States, which went from being a haven for piracy of foreign (primarily English) works to an ardent defender of extending copyright almost into perpetuity (despite there being no incentive benefits in extending copyright retroactively, since the law at the time the work was created was found sufficiently appealing to the original author; sorry, I feel a rant coming on…). Ahhh, imagine this alternate universe. <– That’s a great link, by the way, well worth a click.

Seven Things for April 2, 2015

I haven’t made one of these link posts for awhile. This one’s recent news, the ones to come will have more fun stuff.
